BD680
STMicroelectronics
Images are for reference only.
See Product Specifications for product details.
Buy BD680 with confidence from GFG-TX.com, 1 Year Warranty
See Product Specifications for product details.
Buy BD680 with confidence from GFG-TX.com, 1 Year Warranty
Request a Quote
Dowload BD680 Datasheet| Part Number | BD680 |
|---|---|
| Manufacturer | STMicroelectronics |
| Description | TRANS PNP DARL 80V 4A SOT-32 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| In Stock |
||||||
| Reference Price (In US Dollars) | Get a quote | |||||
- Product parameter
- Related products
- Related news
- Data sheet
Product parameter
| Part Number | BD680 |
|---|---|
| Manufacturer | STMicroelectronics |
| Product Category | Transistors - Bipolar (BJT) - Single |
| Description | TRANS PNP DARL 80V 4A SOT-32 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 145366 pcs |
| Datasheet | BD680.pdf |
| Voltage - Collector Emitter Breakdown (Max) | 80V |
| Vce Saturation (Max) @ Ib, Ic | 2.5V @ 30mA, 1.5A |
| Transistor Type | PNP - Darlington |
| Supplier Device Package | SOT-32-3 |
| Series | - |
| Power - Max | 40W |
| Packaging | Tube |
| Package / Case | TO-225AA, TO-126-3 |
| Other Names | 497-5716 |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Through Hole |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Frequency - Transition | - |
| Detailed Description | Bipolar (BJT) Transistor PNP - Darlington 80V 4A 40W Through Hole SOT-32-3 |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 750 @ 1.5A, 3V |
| Current - Collector Cutoff (Max) | 500µA |
| Current - Collector (Ic) (Max) | 4A |
| Base Part Number | BD680 |
GFG-TX.com is a Reliable Stocking Distributor of Electronic Components. We specialize in all STMicroelectronics series electronic components. We have 145366 pcs of STMicroelectronicsBD680 in stock available now. Request a quote from electronics components distributor at GFG-TX.com, our sales team will contact you within 24 hours.
